IK6BGJ Italy flag Italy

Login is required for additional detail.

Email: Login required to view

Ham Member Lookups: 94861



Free counters!



Map



my Antennas view from the SKY



the ultimate aerial view of my Antennas



. ..a View of my location 136 meters above the Sea level, Just one kilometer from the Adriatic beach...!

a Street View of my first Antenna Setup...

....my second Antenna Setup....

......This is the third setup with the 2 Elements Yagi for 17 M....

.



MY NEW IDEA................ a Homemade 3 elements DELTA loop for the MAGIC BAND 50 Mhz...... June 11 , 2013





......and it works really well.....



What do you think?

Thanks for the visit





MY SURPLUS CORNER





THE TRANSMITTER BEFORE RESTORATION



.a Vintage setup of my shack...

My new Shack with the NEW ENTRY :- the IC 765



The BIG........ FT 1000 D

........ in Memory of a good friend : Nando i6 JHA



x

My Simple 17 meters HOMEBREW ONE ELEMENT DELTA LOOP to the North America

my Delta Loop Page

...Sunset over My delta loop...

Good Morning from Pescara





....Flying over PESCARA...On Board jet Airbus A320









this place up two years ago.........



the same place two years after with THE TWIN TOWERS....from another Aircraft









PESCARA SEA BRIDGE...........the INITIAL IDEA.........|

...I believe that the result is Impressive....















The SEA BRIDGE in the Snow...............

Night view of the SEA bridge

The bridge tower....

Pescara Sea Bridge by Nigth

PESCARA BEACH photographed by myself

...I hope you like it......



My homemade.QSL CARD


DELTA LOOP PAGE ATV PROJECT INTERESTING LINKS
J POLE PAGE FOX HUNTING LASER PROJECT

Justin Page



I K 6 B G J



. . . and now, I present you . . .

. . . My new antenna,know as " SOMMER DX BEAM"

restored successfully after 25 years with a month's work and installed in December 2010

It is a 4 meter BOOM with Three Elements FULL SIZE IN 20 meters without TRAPS,but with A LINEAR LOAD SYSTEM for the others bands.

It works with:

Three full size elements in 20 Meters

FIVE elements in ARRAY type in 10 Meters

FOUR elements in ARRAY type in 15 Meters

ELEMENTS SPACING:-2 Meters between elements on 20m.

Installed on the tower 5 meters over the roof level on the top of a Hill 136 meters

above the Sea level and 1 Km away from the Adriatic Sea












Close view of the feed point and the crossed phase line ..

.. A close view of the Director with the 10 and 15 meters LINEAR LOAD SYSTEM





                  the reflector close view

   t

my Antenna under the ICE





December 16, 2010 a Special Winter Day





...THE NATURE POWER...

A DOUBLE RAINBOW OVER MY ANTENNAS

Work in Progress....

< A simple dipole for 17 Meters... 4 meters over the roof level..

another view of the dipole below the multiband beam



The Dipole is working Well....

...but why not add another element ?

after 3 hours of work the Antenna is on the Air....



and the antenna works day and night ...





my web page IK6BGJ.COM



my QSL are
