DJ7WW Germany flag Germany

Login is required for additional detail.

QSL: EQSL

Email: Login required to view

Ham Member Lookups: 38896



Finally I managed to get my call sign from 1963 back.

Now I use DJ7WW again.

Lots of photos on http://www.pbase.com/df3kv

Antenna work is always in progress

Main tower from top down:

5L20 KLM @44m

2M5WL M² @42.5m

7L10 OWA home brew @41m

3L40 FS @38m home brew, also driven as a rotatable dipol on 80m by omega match

5L20 KLM @31m, fix USA

6L15 KLM @25m, fix USA

5L20 KLM @19m, fix USA

6L15 KLM @15m, fix USA

2M5WL M² @12m on a side swing mount to the east turning 120°

5L20 OWA @10m, fix Russia, modified KLM yagi



This 6-element 15m home brew OWA yagi replaced the previous 4-element 15m yagi at a height of 24m:



Other antennas:

1/4 wave vertical 80m, will turn into 3 element phased array during 2013.

160m elevated GP, on main tower,fed 20m high into the tower and one elevated sloping radial. Plan for 2013 to expand into a 2 element phased array by addition ofan inverted L .

160m dipol@30m

80m dipol @16m

40m 4-square, one elevated radial each above the radial field of the 80m vertical

2L40@18m on Versatower

3L17@20m on Versatower

5L15, 155CA@13m on small tower

6L15 OWA , home brew on 23m high guyed tower

4x 38L +4x 19L +8x 7L on70cm (not mounted at present)

Beverages: to the west 160m long, to north-east 120m long,



This small tower is just 9m high and will be extended during 2013. Plan is to add another 2m of lattice structure, a stronger rotator and a 9m long rotating mast to take a 10m stack of two 5 element yagis above the nearby tree and to move the 155CA and 204BA in between. On the main tower the place of the 204CA will be replaced by another 5L KLM yagi for 20m.

2L40 (HyGain discoverer) at 18m, topped by 3 element 17 now:

Station:

2x IC-765, 2x IC-751A, 2x IC-740, SDR1000, LT-2S transverter for 2m, home brew transverter for 70cm.

Also still use my Drake C-Line for 80m DX.

L4B, IC-2KL

Harris HFL-2500, Henry 2000D converted to 10m, home brew amps with glass tubes QB4//1100 or QB5/1750.

YL1056 and 3CX3000A7 home brew amps for 2m.

TBL2/500 home brew amp for 70cm driven by a pair of 2C39, home brew YL1050 amp.



My dog Sheila born 2008:





































,
