TURKISH AMATEUR RADIO STATION
This is Adem DL4CQ from Germany
Born and live in KA-LI
Welcome everyone in my world
My amateur radio station has equipment for HF, VHF/UHF and satellite operation in CW, SSB/FM,SSTVNBTV-ISSTV-FAX- RTTY-PSK-MFSK-APRS-Hellschreiber and INTERNET REMOTE BASE CONTROLMy interest:anything that has to do with radio in particular digital modes Via INTERNET & ECHOLINK
My RIG
T-BONE SC1100
BEHRINGER UB1832 FX-PRO
PRESONUS
TRX : TS830S - ICOM7400 - ICOM706MKIIG - ICOM225 - ICOM706
FT8900R - TH-F7 - ALAN560 - ALINCO DR635 TS711E
BIGEAR2 - RCI2970 - AE550 - AT600 - TR9000 - MS9150
ANT: ECOGP4B - ECORDIPOL3B - ECOYAGI3B2E
HYGAIN105BA,S5E X30 - X200 - X510
LONGWIRE - M2,9E - TONNA17E - TONNA21E
RF POWER : VLA200 - ROSENKRANSCX250B - KLV1000
My call : DL4CQ-TA6CQ
CLUBCALL : DL0LJ
My EX : DB9EAO - DJ1EAO - TA3CQ
I am the QSL Manager for: M0DOQ-( PA7IM-SK )- TA3CW - DJ1NT - TA3CC
Satellite Downlink Uplink Mode
ITUPSAT1 437.325 FM CW TA1KS
AO-7 145.960 USB 432.160 LSB SSB Phone and CW
AO-27436.795 145.850 FM Phone
FO-29 435.860 USB 145.940 LSB SSB Phone and CW
SO-50 436.795 145.850 FM FM Phone
AO-51 435.150 145.880Primary FM Phone
AO-51435.300 145.920 Secondary FM Phone
VO-52 145.910 USB 435.240 LSB SSB Phone and CW
HO-68435.760 USB 145.930 LSB SSB Phone and CW
ISS 145.800 FM 437.800 FM Phone dig
ONLINE RX FRN-EQSO-25-30MHz
Bizleri burdan dileye bilirsiniz
My CB Call TANGO CHARLY & 13THB1
QRV >>>-------->Ch:21
My CB RADIO
QRG:28.225
INDIRE BILECENIZ AMATÖR RADIO PROGRAMLARI
Dosya Adı
Kb
Açıklama
Ariel30
27 Kb
HF Tel anten dizayn programı
Coax-SWR-dB
184 Kb
Koaksiyel kablo dataları, SWR ve dB hesabı
DXCC126
95 Kb
DXCC Listesini veren program
Free Space
123 Kb
VHF ve UHF de anten yüksekliklerine göre görüşülebilecek mesafeyi veren bir program
Helix Anten
32 Kb
Helix anten hesabı yapabiliyorsunuz
j-Pole
19 Kb
J-Pole anten hesabı yapabilirsiniz
Koax
31 Kb
Koaksiyel kablo kayıplarını hesaplayan bir program
Logp
7 Kb
Logperiyodik anten hesap programı
Mors
126 Kb
Mors çalışmak için çok kullanışlı bir program
Whereitis
124 Kb
Koordinatları verilen iki nokta arası mesafeyi hesaplar
VE3QF
9 Kb
Manyetik Loop anten hesapları
Mloop31
730 Kb
Manyetik Loop anten hesapları
G4FGQLP
69 Kb
Manyetik Loop anten hesapları
RJELOOP1
11 Kb
Manyetik Loop anten hesapları
GP
585 Kb
Graphic Packet Programı (kullanım için tıkla )
BAYCOM
373 Kb
Baycom paket programı (kullanım için tıkla )
WinPack640
1,730 Kb
Winpack Paket programı
Link7
356 Kb
Kenwood TH-D7 iç modemi ile çalışan Paket radyo programı. Program kullanımı için tıklayınız
MCPD7
346 Kb
Kenwood TH-D7 cihaza PC ile kumanda programı
TH-D7V2 rav
36 Kb
Kenwood TH-D7 cihaza PC ile kumanda programı
Hell
721 Kb
Hell çalışma programı
MT63
531 Kb
MT63 Çalışma programı
Smith Abağı
68 Kb
PDF Dosya
TCM3105
243 Kb
PDF Dosya
TH-D7 Manual
2.484 Kb
PDF Dosya
Ham Helper
345 Kb
Genel yardımcı Win 9x programı.
rm_f1st('4','350','true','false','000000','aazsw2cg1vj','false','00ff6c');
Tetrodes
Note:
Sometimes there is more than one data sheet, usually from different manufactuers. E.g. There are data sheets for the 4CX250B from Eimac, STC and Penta. Sometimes there are major differences between the data on the different manufactuers data sheets - you will need to resolve what is right.
Tubes are listed in order of increasing dissipation. So the 4CX300Y is listed before the 4CX350A, since the 4CX300Y has a 400W dissipation
Sometimes two or more tubes share the same data sheet - e.g Eimac 8873, 8874 and 8875.
Manufacturer
Model
Anode dissipation
Cooling
Fmax
Notes
Russian
GU-13
100W
???
30MHz
Eimac
4-125A 4D21
125W
Radiation and forced air
120MHz
4-125
Eimac
4PR125A 8247
125W
Radiation and forced air
-
-
RCA
4-125A 4D21
125W
Radiation and forced air
120MHz
4-125
Eimac
8560A
see notes
Conduction
500MHz
8560. The plate dissipation is limited by the heatsink.
Svetlana
8560AS
200W
Conduction
500MHz
8560
EEV
C1112
250W
Radiation and forced air
110MHz
Eimac
4-250A 5D22
250W
Radiation and forced air
110MHz
4-250
RCA
4-250A 5D22
250W
Radiation and forced air
110MHz
4-250
GEC
CCS1
250W
Conduction
500MHz
CCS1. Similar to the 4CX250B, but conduction, rather than air cooled.
Eimac
4CPX250K 8590
250W
Forced air
500MHz
4CPX250K Pulsed tube. Can deliver in excess if 10kW with 10dB gain at 450MHz.
Eimac
4CS250R
250W
Conduction
500MHz
4CS250. Similar to 4CX250R
Eimac
4CX250B / 7203
250W
Forced air
500MHz
4CX250. The 4CX250B is very popular. 6.0 V heater
STC
4CX250B / CV6136
250W
Forced air
500MHz
4CX250.
Penta
4CX250B/M
250W
Forced air
500MHz
4CX250. An odd make. 4CX250B/M is a new one to me.
Eimac
4CX250BC / 8957
250W
Forced air
500MHz
4CX250. The 4CX250BC is a premium quality 4CX250B, but needs a closer heater voltage
Eimac
4CX250FG / 8621
250W
Forced air
500MHz
4CX250. Identical to 4CX250B, except this has a 26.5 V heater.
Eimac
4CX250K / 8245
250W
Forced air
500MHz
4CX250. Coaxial mount.
Eimac
4CX250M / 8246
250W
Forced air
500MHz
4CX250. Coaxial mount.
Tesla
4CX250M / RE 025 XM
250W
Forced air
1000MHz
4CX250M 4CX250M Coaxial mount
Eimac
4CX250R / 7580W
250W
Forced air
500MHz
See also the data sheet for the 8930 says it is electrically identical except for the larger cooler on the 8930, allowing greater dissipation. The 4CX250R is physically identical to the 4CX250B
Eimac
4X150A (1960 issue) 4X150A (1970 issue)
250W
Forced air
150MHz (500MHz at reduced ratings)
4X150. Identical to 4X150D except for heater voltage is 6.0V on this tube.
Eimac
4X150D (1960 issue) 4X150D (1970 issue)
250W
Forced air
150MHz (500MHz at reduced ratings)
4X150. Identical to 4X150A except for heater voltage is 26.5V on this tube. Data sheet same as 4X150A.
STC
4X250 / CV2487
250W
Forced air
175MHz
4X250. Although electrically equivalent to the 4CX250B, the base seals must be kept below 175 deg C, whereas on the 4CX250B they are okay to 250 deg C.
Eimac
4CW300B
250W
Water
400MHz
4CW300B 4CW300
Amperex
7580W
250W
Forced air
500MHz
7580. Same as 4CX250R i.e. a ruggidised tube.
Philips
QB 3.5/750
250W
Radiation and air
75MHz
Eimac
4W300B 8249
300W
Water
500MHz
Electrically identical to 4CX250B. Reserve anode dissipation
Eimac
4CX300A 8167
300W
Forced air
150MHz
4CX300. A poor quality copy of the data sheet.
Raytheon
4CX300A CK8167
300W
Forced air
500MHz
4CX300.
Eimac
4CX350A / 8321
350W
Forced air
110MHz
4CX350. Good linearity. Identical to 4CX350F except for heater voltage.
Eimac
4CX350F / 8322
350W
Forced air
110MHz
4CX350. Good linearity. Identical to 4CX350A except for heater voltage.
Eimac
4CX350FJ / 8904
350W
Forced air
110MHz
4CX350. IMD performance better than 4CX350F. 26.5V heater.
Eimac
8930
350W
Forced air
500MHz
Electrically idential to the 4CX250R / 7598W, but the larger anode ratiator allows higher dissipation with low air flow and pressure drop.
Eimac
4CX300Y / 8561
400W
Forced air
150MHz
Eimac
4-400A
400W
Radiation
110MHz
4-400. Glass envelope, poor copy, but looks complete.
RCA
4-400A
400W
Radiation
110MHz
4-400. Glass envelope. This might not be a full data sheet, as it's only 2 pages. See also the Eimac 4-400A
Philips
QB 4/1100
400W
Radiation
110MHz
Glass envelope
unknown
Q450-1
450W
Conduction
120MHz
Eimac
4-500A
500W
Radiation
110MHz
4-500. Glass envelope.
Mullard
QY4-500A
500W
Forced air
220MHz
Eimac
4CX600B
600W
Forced air
500MHz
4CX600. The same as the 4CX600F, except 6.0V heater.
Eimac
4CX600F
600W
Forced air
500MHz
4CX600. The same as the 4CX600B, except 26.5V heater.
Eimac
4CX600J / 8809
600W
Forced air
110MHz
4CX600. Highly linear. The Y584 is a specialised version of this tube
Eimac
4CX600JA / 8921
600W
Forced air
110MHz
4CX600. Highly linear.
Eimac
4CX600JB
600W
Forced air
110MHz
4CX600JB 4CX600.
Eimac
4CW800B
800W
Water
500MHz
4CW800.
Eimac
4CW800F
800W
Water
500MHz
4CW800.
Svetlana
4CX800A
800W
Forced air
150MHz
4CX800.
Amperex
4-1000A / 8166
1000W
Radiation
110MHz
4-1000. Glass envelope. See also Eimac 4-1000A
Amperex
4PR1000A
1000W
Radiation
110MHz
4PR-1000. Glass envelope, designed for pulsed use.
Eimac
4-1000A
1000W
Radiation
110MHz
4-1000. Glass envelope. See also Amperex 4-1000A
Eimac
4CPL1000B
1000W
immersion in liquid
---
Pulse modulator, voltage regulator or switch
Eimac
4CPL1000C
1000W
immersion in liquid
---
Pulse modulator or switch
Eimac
4CPL1000A
1000W
immersion in liquid
---
Pulse modulator or switch
Eimac
4CX1000A 8168
1000W
Forced air
110MHz
4CX1000. Some (including me) believe this is a troublesome tube.
Eimac
4CX1000K / 8352
1000W
Forced air
400MHz
4CX1000. 4CX1,000K
Eimac
Y-477
1000W
Conduction
unknown
The anode dissipation is believed to be 1000 W, not 1500 W as stated. Check with Eimac.
Eimac
4CX1500A
1500W
Forced air
150MHz
4CX1500. There is also a Penta data sheet for this tube.
Penta
4CX1500A
1500W
Forced air
150MHz
4CX1500A 4CX1500.
Eimac
4CX1500B / 8660
1500W
Forced air
110MHz
4CX1500.
Eimac
4CX1500BC
1500W
Forced air
450MHz
4CX1500BC 4CX1500.
RCA
7213
1500W
Forced air
1315MHz
Russian
7213
1500W
Forced air
1315MHz
Mullard
QY3-1000A
1500W
Forced air
800MHz
Eimac
4CW2000A
2000W
Water
110 MHz
Philips
QBL 5/3500
3000W
Forced air
220MHz
Eimac
4CX3000A / 8169
3500W
Forced air
150MHz
4CX3000
Russian
GU-73B
3500W
Forced air
250MHz
EEV
4CX5000A
5000W
Forced air
30MHz
See also the Eimac 4CX5000A / 8170 below
Eimac
4X5000A
5000W
Forced air
30MHz
4X5000. Very old data sheet. Note its a 4X, and not a 4CX and has a frequency of maximum ratings of only 30MHz. See also the 4CX5000A / 8170 below
Eimac
4CX5000A / 8170
5000W
Forced air
110MHz
4CX5000. Electrically identical to the Eimac 4CX10000D (8171) , except for the later tubes increased anode dissipation.
Eimac
4CX5000J / 8909
5000W
Forced air
100MHz
Eimac
4CX5000R / 8170W
5000W
Forced air
100MHz
4CX5000.
Eimac
4CX7500A
7500W
Forced air
220MHz
4CX7500A 4CX7500.
Penta
4CX7500A
7500W
Forced air
220MHz
Sorry, no Eimac data sheet - only this Penta one.
Eimac
4CV8000A
8000W
Vapor & forced air
150MHz
This is a vapor cooled tube, which is quite rare at this size.
Svetlana
4CW10,000A 8661
10,000W
Water+forced air
30MHz
Rated 10 kW, but the Eimac version is rated 12 kW. That's not a very good rip-off by Svetlana!
Eimac
4CX10,000D 8171
10,000W
Forced air
110MHz
4CX10,000D 4CX10000. 4CX10000D Electrically identical to the 4CX5000A
Eimac
4CW10,000A 8171
12,000W
Water + forced air
110MHz
Svetlana model rated 10kW. Eimac 12 kW (not a very good rip-off by Svetlana!)
Eimac
4CW10,000B
12,000W
Water + forced air
110MHz
4CW10,000B 4CW10000B 4CW10000 4CW10,000
Eimac
4CX10,000J
12,000W
Forced air
100MHz
4CX10000 4CX10000J
Eimac
4CX12000A / 8989
12,000W
Forced air
220MHz
4CX12000 4CX12,000. 4CX12,000A There is also a Svetlana 4CX12000A data sheet though.
Svetlana
4CX12,000A 8989
12,000W
Forced air
220MHz
4CX12000 4CX12000A
Eimac
4CX15,000A / 8281
15,000W
Forced air
110MHz
4CX15000 4CX15,000
Eimac
4CX15,000J 4CX15000J 8910
15,000W
Forced air
110MHz
4CX15000 4CX15,000
Eimac
4CX15,000R
15,000W
Forced air
110MHz
4CX15000 4CX15,000. See also Svetlana 4CX15000R data sheet.
Svetlana
4CX15,000R
15,000W
Forced air
110MHz
4CX15000R 4CX15,000R.
Eimac
Y-863
15,000W
Forced air
220MHz
Y-863
Eimac
8989
15,000W
Forced air
220MHz
Formally X-2219
Eimac
4CX20,000A / 8990
20,000W
Forced air
110MHz
4CX20000 4CX20000A See also older 8990 data sheet
Svetlana
4CX20,000A / 8990
20,000W
Forced air
110MHz
4CX20000 4CX20,000A
Eimac
4CX20,000B
20,000W
Forced air
30MHz
4CX20,000B 4CX20000B 4CX20,000.
Svetlana
4CX20,000B
20,000W
Forced air
30MHz
4CX20000B 4CX20000 4CX,20000
Eimac
4CX20,000C
20,000W
Forced air
110MHz
4CX20,000C 4CX20000C 4CX20,000.
Svetlana
4CX20,000C
20,000W
Forced air
110MHz
4CX20000 4CX20,000.
Eimac
4CX20,000D / 9015
20,000W
Forced air
110MHz
4CX20,000D 4CX20000 4CX20000D.
Eimac
4CX20,000E
20,000W
Forced air
110MHz
4CX20,000E 4CX20000E 4CX20,000.
Eimac
8990
20,000W
Forced air
220MHz
Formally X-2213
Eimac
4CX25,000A
25,000W
Forced air
230MHz
4CX25000 4CX25000A
Eimac
4CX25,000C
25,000W
Forced air
110MHz
4CX25000 4CX25000C
EEV
4CW25000A
25,000W
Water
110MHz full, 225MHz reduced
Does anyone have an Eimac data sheet for the 4CW25000A?
Eimac
4CW25,000A
25,000W
Water
110MHz
4CW25,000A 4CW25000A 4CW25000.
Eimac
4CW25,000B
25,000W
Water
110MHz
4CW25,000B 4CW25000B 4CW25000.
Eimac
4CW30,000A
30,000W
Water
110MHz (220MHz reduced)
4CW30000 4CW30000A
Eimac
4CX30,000G
30,000W
Forced air
110MHz (CW) 230MHz (TV)
3CX30000 4CX30000G
Eimac
4CV35,000A
35,000W
Vapor
110MHz
.
Eimac
4CX35,000C 8349
35,000W
Forced air
30MHz
Eimac
4CX40,000GM
40,000W
Forced air
250MHz
4CX40,000GM 4CX40000GM 4CX40000.
Eimac
4CV50,000E
50,000W
Vapor
110MHz
4CV50000E 4CV50000
Eimac
4CV50,000J
50,000W
Vapor
110MHz
4CV50,000J 4CV50000J 4CV50,000
Eimac
4CW50000E
50,000W
Water
110MHz
4CW50,000E 4CW50,000E 4CW50000
Eimac
4CW50,000J
50,000W
Water
110MHz
4CW50000 4CW50000J
Eimac
4CW100,000E
100,000W
Water
108MHz
4CW100000E Needs SK-2100 water jacket.
Eimac
4CW150,000E
150,000W
Water
108MHz
4CW150000E 4CW150000
Eimac
4CV250,000B
250,000W
Vapor
50MHz
Great for QRP 4CV250000B
Eimac
4CW250,000B
250,000W
Water
50MHz
Great for QRP 4CW250000B
Eimac
4CM300,000GA
300,000W
Multiphase
50MHz
Eimac
4CPW1000KA / 9009 / X-2026K
1MW
Water
---
No good for QRP as this is a switch tube.
Eimac
8973 / X-2170K
1MW
Water
110MHz
The ultimate tube for QRP
The site does not have every data sheet. Some are missing. If you have any of wanted list please let me know. You can upload them directly to my web server (this is on another domain, but don't worry about that). For security reasons, to stop hackers and spammers, the files will be unreadable until I have checked them fully.
