144Mhz antenna : M2-18xxx + pre SP2000 +400W GI7B

432Mhz antenna : 25 el I0jxx +pre SP7000

1296Mhz antenna : 55 el F9ft +pre SP23

2320Mhz antenna : 1m dish TRV DB6NT 5W + pre 20db

5.7Ghz : trv DB6NT 200mW

10GHz : antenna 90cm off set TRV SSB elect. 2W pa + pre

MY BEACON :

IZ1DYE/B 70.105 Mhz 1300msl JN35PA (on air 01/02/2012 - 31/12/2012)

IW1AVR/B 144.404 Mhz 1300msl JN35PA ( ON AIR !! )

IW1AVR/B 432.410 Mhz 1300msl JN35PA (ON AIR !!)

IZ1DYE/B 1296.945 Mhz 1300msl JN35PA ( ON AIR !! )

IZ1DYE/B 2320.889 Mhz 1300msl JN35PA ( ON AIR !! )

For more information visit my web page http://www.iz1dye.it/BEACON.htm

My project : Hi dynamic replacement board for FT225RD:

PREAMPLIFIER : ATF54143 GAIN 15db NF <0.5db IP3 +36dbm
RING MIXER : SBL1-MH +13dbm
IF FILTER 10.7MHZ : Roofing filter 6.5 KHz

SMD , CAD DRAWING

73 de Michele IZ1DYE
