KC9WKE VOIP SYSTEMS



DSTAR GATEWAY KC9WKE

446.500Mhz MODULE B (DVRPTR)

147.400Mhz MODULE A (DVAP)



KC9WKE 446.500 DSTAR SIMPLEX GATEWAY

German board DVRPTR V1 online and enabled for DSTAR hot spot use ON 446.500 Mhz simplex. YOU MUST SET THE OFFSET TO PLUS + OR - MINUS WITH A ZERO SHIFT. The board will allow area dstar users to connect to any reflector by DTMF, this includes all DPLUS, XREF and DCS reflectors. The callsign is KC9WKE (MIDWEST VOIP USERS ARC) The linking software used is G4KLX and currently have 2 modules running, A and B. The A module has been reserved for personal use and is a DVAP Dongle that has a limited range of 1000 feet. The B module is the German DVRPTR attached to a Yaesu 7800 with an output power of 50 watts maximum and provides usage for mobile rigs on 446.500Mhz. All hams are welcome to use the gateway.

NOTE: I NOW HAVE A YAESU WIRES X HRI-200 ON ANALOG 446.500  IF YOU SEE THE KC9WKE GATEWAY B IN THE REPEATER MODULE TO THE RIGHT WITH A RED DOT THIS MEANS THE DSTAR GATEWAY REPEATER B IS OFF LINE AND THE WIRES ANALOG IS ON. THE WIRES NODE IS 11017 AND ROOM IS 21017 TO CONNECT TO A WIRES NODE OR ROOM USE #XXXXX (XXXXX = 5 DIGIT NODE OR ROOM NUMBER) TO CONNECT AND A STAR TO DISCONNECT. MORE TO FOLLOW ON ACCESS CODES

RADIO SETTINGS FOR ACCESS:

YOUR: CQCQCQ RPT1: KC9WKE B

RPT2: KC9WKE G MY: YOUR CALL SIGN



Offset MUST be set to + or - with a zero shift
(simplex but with - or +)



DTMF ACCESS

0 (ZERO) for status

# (HASH) for disconnect

REF REFLECTORS: * PLUS 2 DIGIT REFLECTOR NUMBER AND A B C or D FOR MODULE IE: *01C CONNECTS TO REFLECTOR 1C

XRF REFLECTORS: B PLUS 3 DIGIT REFLECTOR NUMBER AND A B C or D FOR MODULE EXAMPLE: B901A B587A

DCS REFLECTORS: D PLUS DCS REF NUMBER PLUS MODULE NUMBER 01 - 26 (A-Z) IE: D502 or D00502 CONNECTS TO DCS REF 5B

CCS & IRCDDB DIRECT ROUTING, GATEWAY ROUTING AND STN ACCESS IS ALSO AVAILABLE !

Current Experimenters group network:

http://w4icy.inerrantenergy.com/arec.html





ANALOG GATEWAY

Simplex 144.910Mhz 100.0hz Tone Required

ALLSTAR TRANSMITTER NODE 27915

This analog system can communicate with the following voip systems

1. Allstar: *3 plus allstar node number

2. Echolink: *33plus 6 digit echolink node number (read explaination on connections to el below

3. IRLP: access available upon request

4. *Dstar Digital: *You must link to an Allstar, Echolink or IRLP node that carries a dstar node. The KC9WKE system currently carries XRF901A on Allstar node 28791. You can access this by linking to 28791. All audio is sent to XRF901A via a dvdongle and the Dstar channel driver in Allstar. If you would like to converse with a friend who has dstar he would need to connect his dstar radio to XRF901A. The link can be changed upon request but normally resides on XRF901A (The Experimenters Corner)



Currently the analog node connects at noon CST to the Alaska Morning Net for one and a half hours Mon-Fri on IRLP 9109 local amateurs are welcome to partisipate.

Allstar node commands always begin with the

asterisk*

*3 plus ALLSTAR node number CONNECTS to ALLSTAR node ie: *327915

*1 plus ALLSTAR node numer DISCONNECTS ALLSTAR node ie: *127915

*70 CURRENT ALLSTAR NODE STATUS
*71 DISCONNECTS ALL
*80 FORCE ID

*81 TIME OF DAY

CONNECT MACROS

*530 ALASKA MORNING NET (IRLP 9109)
*531 SOUTHCARS (ALLSTAR 27404)
*532 IRELAND CONFERENCE (ECHOLINK 2605)
*533 WAN SYSTEM PENNSYLVANIA (ALLSTAR 2135)
*534 DODROPIN (ECHOLINK 355800)
*535
*536 WIN SYSTEM (IRLP 9100)



DISCONNECT MACROS

*550 ALASKA MORNING NET (IRLP 9109)
*551 SOUTHCARS (27404)
*552 IRELAND (ECHOLINK 2605)
*553 WAN SYSTEM (2135)
*554 DODROPIN (ECHOLINK 355800)
*556 WINSYSTEM (IRLP 9100 )



ALLSTAR TO DSTAR BRIDGE 28791


This node is currently bridged to Dstar XRF Reflector 901A with a DVDONGLE. If you link to this node all audio will be sent to the reflector via the dvdongle in digital DSTAR.


ECHOLINK NODE 816990



TO MAKE OUTBOUND ECHOLINK CALLS:

enter *33 plus the echolink node number you wish to connect to.

Allstar requires Echolink nodes must contain 6 digits. If the Echolink node you want has less than 6 digits, you must pad zeros prior to actual node number.

Example: to connect to EchoLink Node 2605 you must use *33002605

*33 plus padded node 002605. Because there are only 4 digits in the node number, 2 zeros are added to beginning to make the 6 digits. This is for Echolink link nodes only.

To DISCONNECT you will use *71



TO LISTEN FOR INCOMMING EL CONNECTIONS:

All incomming calls from Echolink are directed to node 28785, if you have instructed someone to connect to the MIDWEST VOIP USERS echolink node 816990 you must connect (link) to allstar node 28791 (use *328785 to connect (link). You then can talk and listen to incomming el calls.





If you would like a macro setup to connect to ANY voip node, please contact me and I will create a DTMF shortcut for you!





LIVE VIDEO

The City of St Louis, Missouri skyline with the arch is known as the gateway to the west. The picture below shows when I am not broadcasting on ustream, this is very close to my QTH.



INSTRUCTIONS WHEN BROADCASTING

Click on the small play button on the white bar at bottom of stream picture to start. A short advertisement will play then the feed will start. If you click on the large play arrow on the picture, it will navigate to Ustream site and play the feed



73 and thank you for visiting our QRZ page























CURRENT ALLSTAR NODE STATUS

TRANSMITTER 144.910 Mhz

ECHOLINK 816990 KC9WKE-L

DSTAR BRIDGE TO XRF 901 A

ALLSTAR TEST NODE

ALLSTAR HUB NODE



ACTIVE ALLSTAR NODES
