LEFT A3S ON TOWER AT 40 FT. ON RIGHT A3S AT 40 FT ON A CRANK DOWN / TILT OVER LADDER

A3S AT 40 FT ON A CRANK DOWN / TILT OVER LADDER



ICOM AH-4 RANDOM WIRE OUTDOOR ANTENNA TUNER.
FOR LIGHTNING PROTECTION
WHEN NOT IN USE OUTDOOR RELAYS DISCONNECT ALL ANTENNAS, COAX, AND WIRES
FROM THE AH-4 AND GROUNDS THEM TO CHASSIS.



ICOM RADIO AND AH-4 TUNER
FOR LIGHTNING PROTECTION
WHEN NOT IN USE INDOOR RELAYS DISCONNECT ALL WIRES
FROM THE IC-7600 AND GROUNDS THEM TO CHASSIS TO PROTECT THE RADIO.



ICOM AH-4 TUNER CONTROL
THIS BOX IS SEQUENCED SO THE RADIO WILL NOT CONNECT UNTIL
THE OUTDOOR AH-4 IS CONNECTED TO THE WIRES AND NOT GROUND.
THIS PREVENTS THE 12 VOLTS FROM THE RADIO
GOING TO GROUND OUTSIDE AT THE AH-4 TUNER.
