                                     I was born in 1949 north of JAPAN Akita.

It was a dream to discharge an electric wave towards sky from a child's time.
Ham license try to the April, 1968 at the time of high school.
They are the days which have discharged the electric wave to the world towards sky
since then by amateur radio as it is in a "JA7GYP-ham history."
Now,I have enjoyed again the amateur radio by retired over to Nov 2012 worked long.

JA7GYP also has licensed the 1kW power at 1.8MHz-50MHz.
The operating frequency is 135kHz(100W) 475kHz(50W) to 430MHz(50W).
Having had my two towers,top of 38m hight and 24m hight has been set dipole, yagi beam antennas.
160m band antenna is Shunt feed. 6m band is 7ele long john into 1kW only DX.
135kHz transmitter is TX2200A (Tham Way),475kHz transmitter is NSC-17(JRC) &
the receiver NRD-535D (JRC) has been use now.
HF band operation of theIC-7800/IC-7000(iCOM) and linear amplifier JRL-3000F(JRC) it's FET type.

Computer PC Windows 10      Software: MMTTY, MMVARI, MMSSTV, JT65HF,N1MM Logger ect.

Two Tower(L:DX-1600 R:KT22R)


160m TX Antenna Remort control system    Matching Section & Tower(38m Top) & Shant feed element(20m)


 *** DMI kei ***  Digital Mood Interface & Volume adjustment for TX ACC(In/Out)

It is handmade with LED(4 colors) display mode is Red-PTT,Green-RTTY(FSK),Blue-CW,
Yellow-SEND(Liner TubeAmp,RX PreAmp standby).
These are displaying modes JT65,RTTY(FSK),PSK,Digital CW & N1MM Logger+.

I arrange the LED display in diamond shape and Lights are beautiful like fireworks.
The transceiver operation is possible by PC with CAT(CI-V) connection.
You can also read frequency and change the band/mode to DMI.
For details, please go to my blog !!

I was awarded with the # 7,977 on June 5, 2014 the 5 B DXCC only LoTW.





 I was awarded with the 339/343 entities #1 Honor Roll Mixed on March 2016.


  Top of HR Plaques     #1 HR Lapel Pins

                          akitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakitakita

CQ ZONE 25,ITU ZONE 45 AKITA city(about 500km north of Tokyo)
GL: QM09BQ
IOTA: AS-007
JCC: 0401
Member of ADXA(The Akita DX Association) & LoTW

Vy Tnx from Kei JA7GYP




July 2016 Operating desk de JA7GYP       The DXpedition sometimes enjoying at V63T(V63KF)
