WP4OPF USA flag USA

Login is required for additional detail.

QSL: POSTAL MAIL, EQSL, LOTW.

Email: Login required to view

Ham Member Lookups: 33795



Operating Bands: 160, 80, 60, 40, 20, 17, 15, 12, 10, 6, 2 meters and 70cm
Thank you for visiting this page and for our QSO ?. . I look forward to our next contact. 73 for now Doel
    Please confirm contact via QRZ log or EQSL,
POSTAL MAIL.

I upload to LOTW,QRZ log and EQSL [every day that I am on the air]


Thanks for stopping by!

   THE STATE OF FLORIDA

WELCOME  TO Citrus County

EST: Eastern Time (GMT-05:00 )

















Puerto Rico





Standard Time Zone: UTC/GMT -4 Hours



PR 781

SPECIFICATION
Generating Element: Heil PR Dynamic
Frequency Response: 50 Hz to 16,000 Hz
Impedance: Balanced 600 Ohms Out, 3 pin
Polar Pattern: Cardioid
Output Level: -55 dB
Diaphragm: Low-mass aluminum
Finish: Black Satin Epoxy
Net Weight: 14 oz.

FS-3

The FS 3 is a single channel foot switch to control the transmit/receive function of an amateur radio transceiver. An 8' shielded cable is terminated with a commercial 1/4" plug connects into the Heil CC-1 and AD-1 cable system.


SCU-17

USB INTERFACE UNIT

Control Transceiver by CAT communication
 Communication by various digital modes such as RTTY(FSK/AFSK),PSK31,and SSTV
 CW Operation by PC software (PC keying)
 Input/output of audio signal through the USB interface (recording, modulation, etc.)
 Firmware updates on some radios

SCU-17 features:
* Provides CAT communications through USB when PC does not have RS-232C port.
* Has a USB audio system so the TX and RX audio is accessible through the USB cable.
* Has a two-channel USB serial device and enables various transmit modes and CAT comms. simultaneously.
* Operates from USB bus power, so no external power supply required.
* Provides high RF isolation via photo relays.
* Front panel TX and RX audio controls.
* LED indicators monitor PTT and FSK control.

Compatible with: FT-450D, FT-817ND, FT-857D, FT-897D, FT-950, FT-2000, FTDX1200, FTDX5000, FTDX9000

Optional Accessories

YAESU SCU-21 INTERFACE CABLE for FT-2000 & FT-DX5000 Series






YAESU FTDX 5000MP

YAESU FTDX 9000D



YAESU

For a bold, clean signal from "Top Band" through the "Magic Band," the VL-1000/VP-1000 QUADRA SYSTEM belongs in your station! Innovative Ouadra Push-Pull RF Design for 1 kW of MOSFET Power! Yaesu's engineers have conquered the challenging task of providing high power output from 160 through 6 meters!* Yaesu's exclusive Quadra Push-Pull design utilizes 8 rugged MRF-150 MOS FETs for years of reliable operation. Special attention to system grounding and RF bypassing ensures very low spurious emissions, even at maximum power output.

HUSTLER 5-BTV

HF VERTICAL ANTENNA
 5-Band 80, 40, 20, 15, 10 meters
+ Add On 60M, 17M and 12M
 HF Vertical Antenna Type:Multi-band, resonant
 Antenna Power Rating:1,500 W
 Vertical Antenna Height:25.10 ft.
 Antenna Weight:17.00 lbs

DX Engineering 60 Meter Add-On Kits DXE-AOK-60M

DX Engineering 60 Meter Add-On Kits DXE-AOK-60M

Finished "mod" showing 12 and 17 Meter add on verticals

"The very first time I fired it up, the SWR was less than 1.1.
So I left it alone.

The formula for cutting the wire length is the old standby:
234 / Freqmhz = length in feet.
I used 13 feet for 17 meters and 9 feet 5 inches for 12 meters



DX Engineering

Vertical Feedline Current Choke Kit
         VFCC-H05-A

         50 to 50 ohms
         1.8 to 30 MHz

         2 KW Continuous
       5 KW intermittent

DX Engineering Radial Plates are made of 304 Stainless Steel,

1/8 inch thick and 11.625 in. x 11.625 in. outside dimensions.



VHF/UHF Slim Jim J-Pole Dual Band 2m 70cm Antenna

Comet GP-6 - Dual Band

                                                       YAESU FT-7800 R

















Flag Counter

Flag Counter

Flag Counter Flag Counter


Large Visitor Globe






Thanks for stopping by! 73
