VK4JU Australia flag Australia

Login is required for additional detail.

QSL: BURO, LOTW AND VIA DIRECT

Email: Login required to view

Ham Member Lookups: 35254



Above picture is a Homebrew 2 Element Swiss Quad for 12m,15m,17m,20m. Main station consists of Icom IC7600, Acom 1000 Amplifier, Palstar AT1500cv ATU, Begali (key) Signature Edition paddle, Revex W560, Alpha Delta 4. and Swiss Quads for 6m,10m

For Direct Qsl I need SAE.         I do QSL VIA Bureau but only answer cards received.

Also a Homebrew 2 Element 40m wire Beam antenna (designed by vk2abq it's like a Moxon) with a balanced feedline at 50 feet in the palm treessmiley





Left Vk4ju. Always wounderful when my Dad (Ian Vk3bmo) visits my Qth.



                 My Qth   Trinity Beach   Cairns





I received my novice license in June 1979 (Vk3vev) at the age of 15. My first rig was a TS520s my Dad (now Vk3bmo) already had in the shack. When I upgraded to unrestricted license I received Vk3idx February 1992. I moved from Melbourne Victoria (Vk3) to north Queensland (Vk4)1996 and became Vk4idx then Vk4ju

I now work in the tourism industry as a coach Driver and work on reef tour Boats.

                               My Homebrew 2 Element Swiss Quads

 Above's Homebrew Swiss Quads for 10m,6m and 12m,15m,17m,20m

The Swiss Quad (Designed by HB9CV) is an all driven array.

It differs from the conventional quad electrically in that both elements are driven - with a phase difference of 180 degrees.

The horizontal elements are aluminium tubing and the vertical

elements are wire. I fed the loops by means of a T-match

(double gamma match) system.

CLAIMED PERFORMANCES

Gain against a dipole at short distance 6 to 7.9 dB

Gain against a dipole at long distance 12 to 14 dB

F\B at 15km 15 dB

F\B at 1000km 10 to 12 dB

F\B at 3000km 18 to 24 dB

6m

Below's : Old Antenna ARRAYs

10m

Swiss Quad 10m,17m,20m

Thank you for looking

Good luck and good DX 73's

AX4JU  Special event callsign ANZAC Day 25-April

since 30-9-2014

free counters

                                                                                           FLAG COUNTER SINCE 27-1-2011

My Car Australian made GMH 2012 model Holden commodore with a 6 litre V8 L77 Alloy Chevy (Enhanced) engine. Runs on 98 Octane fuel

                                                What I find in my garden.  Birdwing Butterflys and Ulysses Butterflys

Above we have a Beautiful Little yellow Sunbird, Green Tree Frog and a Spotted python, Golden orb spider

A large 4 meter crocodile in the Mowbray River under the Captain Cook Highway bridge. Just before Port Douglus
