ZS4A South Africa flag South Africa

Login is required for additional detail.

QSL: LOTW,Clublog, E-Qsl ,Qrz.com and via e-mail on reqest.

Email: Login required to view

Ham Member Lookups: 64403



PLEASE READ QSL POLICY LOWER DOWN





My very basic 144Mhz EME Station:

winksmiley

EME Stations worked on 2m: all the following QSO's was made without a LNA (Low Noise Amplifier)  and 2X10 element H-POL Yagis @ 160 Watt TX power ....thank  you all for your great effort and Ham Spirit!!

 I2FAK         Franco    (Italy)       ( 2X CONTACTS )  ,    OZ1LPR     Peter       (Denmark)   , PA0JMV     Joop        (Netherlands)       ,   DF2ZC        Bernd     (Germany) ,  KB8RQ       Gary       (USA)   , K7MAC      Ronald    (USA)    , ES6RQ      Ants          (Estonia)     , ES3RF    Gennadi      (Estonia) ,     RX1AS      Sergey     (Russia)  , PA2CHR    Chris      (Netherlands)  ,   DK5LA    Reinhard  (Germany)   DK3BU  (Germany)  ,  RU1AA    Alex           (Russia)  ,  RK3FG      Anatoly    (Russia)  ,   I3MEK      Mario      (Italy)      ( 2X CONTACTS)  ,   PA5Y     Conrad    (Netherlands)    ( 2X CONTACTS)  , YT1AR    Dan     (Serbia)  ,S52LM    Milos    (Slovenia)  , UA3PTW     Dimitrij    (Russia)  , PE1L      Rene   (Netherlands)  ,   RZ3BA/1   Vlad    (Russia)  , SM5DIC    Gus  (Sweden)  , DL9MS  Joe   (Germany)   , G4SWX   John  (England)  , RX3A    Nikolay  (Russia)   SK5AA    (CLUB)   (Sweden)  , YU7AA     Jozsef    (Serbia)  , DK5SO     Kurt       (Germany)   ,  F6HVK     Andre    (France)  , EA2AGZ    Nicol     (Spain)     W5ZN      Joel   (USA) ,   UX5UL  Oleg    (Ukraine) ,  UT6UG   Val     (Ukraine) , YU7XL    Boban    (Serbia)  , OH4LA     Pasi     (Finland) ,   DK3WG     Jurg    (Germany)  , HB9Q        Dan      (Switzerland) ,   RW1AY      Vlad    (Russia)   ,  K9MRI      Joe    (USA)  , OK1DIX    Ladislav  (Czech Republic).

all the following QSO's was made without a LNA (Low Noise Amplifier)  and 4X10 element H-POL Yagis @160 Watt TX power :

JR3EXR  Taka  (Japan) , S56P  Bostjan   (Slovinia)  ,  JR3REX  Seiichi (Japan) , ZS5HV  Hugo  ( South-Africa) ,UA4AQL  Al  (Russia) ,  TM8DO  Marius  (France) , SM5CUI  Rune  (Sweden) , G4YTL  David  (England) , I3MEK   Mario  (Italy) , OZ1CT  Ben  (Denmark) , IK7EZN  Ermanno  (Italy) , ZS6JON John  ( South-Africa) , Paul F4DJK  (France)  ,  Jacinto EA5CJ (Spian)  ,  Pista HA8CE (Hungary)  , Martin OK1UGA (Czech Republic) ,  Gary N5KDA (USA) ,











2 X 10 Element OWL Yagis (6m Booms Homebrew) with 50 Ohm power devider by ZS6OB       (OLD SETUP)

63mm Fiberglass spreader boom carrying the antennas about 8m high, on tilt over tower.

I have a 160Watt TX power capability .

(OLD SETUP)





New 4 X 10 H-POL Array installed 28-12-2016



Very basic Rotor system control box  for homebrew EL/AZ Rotors









THIS DX GROUP WAS CREATED BY ME ON THE 22nd OF JANUARY 2015 WHEN MY SON AND VERY GOOD FRIENDS OF MINE BECAME RADIO HAMS. WE HAVE A CLOSED GROUP ON WhatsApp ON OUR CELLPHONES WHICH BROADCASTS  RARE DX STATIONS AND OTHER STATIONS WE WORKED OR HEAR, WITH CALLSIGN AND FREQUENCY THEY ARE ON,TO GIVE THE GROUP A CHANCE TO WORK THEM.WE ALL CARRY ZS4   CALLSIGNS AND REPRESENT THE CENTRAL PART OF SOUTH-AFRICA CALLED THE FREE-STATE PROVINCE.

CURRENT MEMBERS:

ZS4A (Group Custodion) , ZS4SDL , ZS4AZ , ZS4LD , ZS4RC , ZS4MK , ZS4VLS, ZS4JLE ,ZS4JAM.







My Mobile Nr: +27 83 3841497

MEMBER OF THE S.A.R.L



Active on all HF freq. With Phone,SSTV,Bpsk,Rtty,JT65+JT9+FT8

(2 - 5 watt output) and Wspr +  LEO Sattelite communications and 144Mhz EME.

PLEASE NOTE:

IF I DO NOT ANSWER YOU WHEN YOU ARE CALLING,THEN I TRULY CANNOT HEAR YOU,I WOULD LOVE TO WORK AS MANY STATIONS AS POSSIBLE SO BE PATIENT AND TRY LATER AGAIN OR INCREASE YOUR TX POWER IF POSSIBLE, LET US ALL ENJOY THIS HOBBY/RADIOSPORT

Working SaudiSat-1C (SO-50) RaDAR Style with some Friends













QSL POLICY:

PLEASE NOTE: I DO NOT SEND ANY PAPER QSL CARDS (EXEPT FOR EME CONTACTS)ONLY ELECTRONIC VERSION ON REQUEST CAN BE E-MAILED,YOU WILL SEE IT FURTHER DOWN THE PAGE. I DO UPLOAD LOGS TO (Lotw,E-Qsl ,Clublog and QRZ.com)









This is my Electronic QSL Cards.







 -LOGBOOK

















Station Details:

Kenwood TS- 950SDX HF Tranciever for DX.

Yaesu FL-2100 Linear Amplifier.

DAIWA  CNW  2.5 KW  Antenna Tuner.

TH5MK2  Thunderbird 5 Element 3 Band  Yagi  @ 60Ft/18M   High.

12 Element 144Mhz H-Pol beam @ 22M/72Ft high.

40M Inverted V monoband +80M Inverted V monoband

4 X 10 H-POL EME Array for 144 Mhz EME work @ 160Watt output from a Daiwa LA-2180HK Amplifier.

Kenwood TS- 2000X  All mode Multibander   Tranciever.

Microphones:  HEIL Proset Plus   and    HEIL PR 781

Mobile Station:

ICOM  IC - 706 MK2 G   Tranciever.

Little Tarheel 2   (80-6M )  Multiband HF Antenna.

Surmen SG-7900 High Performance Dual band 2m/70cm antenna.





NEW TOWER AND ANTENNA INSTALLED17-08-2013.THUNDERBIRD TH5 MK 2 TRI-BANDER FROM HY-GAIN 60FT/18 M HIGH.

Bottom photo, 12 element H-POL 144Mhz beam @72Ft/22m high and EME tower 8m high with 4 x 10Element OWL Yagis.





3 Element Vhf / 8 Element Uhf Antennas For Satcomms FM/SSB + 23 Element

GTV70-23 "BLADE DIAPOLE" HOMEBREW YAGI (DG7YBN DESIGN)  for long distance 70cm Tropo contacts.

The following photos was taken from a BELL 407 Helicopter when we did a flyby.



Arial view of QTH and antenna



Closeup view of the Homebrew Tower and Beam by Hy-gain.

Station Layout:



Kenwood TS-2000X All Mode Multi Bander

Kenwood  TS-950 SDX    HF Tranciever

Default microphone mostly used: HEIL PR 781



Something exstra for some heat



ANTIQUE MODULATION (AM) STATION FOR MUSICAL TRANSMISSIONS





MOBILE STATION:

LITTLE THARHEEL2 (80-6M) ANTENNA

HIGH PERFORMANCE 2M/70CM SG-7900 DUAL BAND ANTENNA

ICOM IC-706 MK 2 G  TRANCIEVER









CLUBS:







Myself and my wife Heidi (ZS 4 ZA) and our two Sons Stephan (ZS 4 SDL) (left) and Brandon(right).







free counters

free hit counter

free hit counter


ANTENNA PROJECTS IN 2015:

2m+70cm Bow and Arrow SAT Comms portable antenna.

Completed Bow&Arrow

2m x 12 element for SSB Horisontal work, wil be going up to 22m on tower.

12 Element 2 meter Yagi's feedpiont and Gamma Match



26 September 2015:



Prepairing for installation of the 12 Element 144Mhz  Long boom Yagi by my Son, Stephan ZS4SDL.

Up through the big beam and waiting for the 4m mast to go up.

Getting the direction correct to correspond with the TH5 Beam.

Job done and only tying the coax feeder to the tower all the way down, he did a fantastic job up there alone in 33'C and took him 4 hours in the hot Sun, thanks a million ZS4SDL.smileyyes



The homebrew Red Bush Tea Tin Tuner (RBTTT).

This was always a joke between friends that this Tuner can tune up a 6 inch nail on 80m band.

The first inline tunning cap and roller inductor dates back from 1945 which was selvaged from an old Navy AM transmitter and the dual cap was in my scrap collection, the very old looking tea tin came from my XYL ZS4ZA which had some needle work stuff in. I thought of spraying the tin but it looks more ancient this way.

This Series/Parallel Capacitance tuner realy works and is a nice to have for field trip stations. Never seen anything tunning like this!!yessmiley


Free counters

Some pictures of my daily work ,a bit of Live-Line (HOTLINE) work on a 132 Kv Line
