Welcome to my shack, my own mancave, feel free to have a look.

To see if you are in the log, please scroll to the bottom of the page.

These are my antenna's, from left to right: Wellbrook ALA1530 loop, Butternut HF5B, Diamond V2000 and a multiband Hyendfed wire antenna.

The Radio Equipment



Lower shelf, leftside: Power Supply, mcHF SDR QRP Transceiver, Tune Button. Rightside: Yaesu FTdx-3000 with Power Supply and FH2. Upper shelf: PC with 2 screens. Left screen used for Rotator and panoramic spectrum display (with-point-and-click) via RTL dongle and HDSDR of FTdx3000. Right screen used for HRD (logbook and DM780) and other programs. Also on upper shelf two times a Timewave ANC-4, a MD-200 microphone and PWR/SWR meter with Modulation display.



Close-up: Below a homebrew Power Supply and the mcHF. The mcHF is home build from the original kit from Chris, M0NKA. This is an outstanding SDR transceiver with a ton of features and open software. A real gem. On the upper shelf a home made PWR/SWR meter with modulation (touch-) screen.

Lower shelf: ERC-4 USB Rotor control, 1 kW antenna coupler for the SWR meter,  Yaesu Rotor, Loop Rotor. Upper shelf: Field strength meter for TX verification, Acom 1010 Linear, Nixie clock, Phone.



Lower left: FT-902DE with SP-901 and FC 902. Right FT736R with SP767. Upper part: Power supply for Led lighting, printer for QSL card labels, NixieTherm, Kenwood TH-F7E, MD-1, PC for CAT control and Power/SWR meters.



Antenna Patch Panel, Airconditioning and a recently home made tube radio, it was made from a schematic called Triolet 2 published in Radio Bulletin 1958 with 5 tubes and has SW, MW and LW. Left from the radio in yellow, the winch control for the antenna mast. At the right the microscope for SMD work.

The workshop with some measuring equipment.

Reading corner and parts supply, part of the "junk box" is at the other side of the wall.

On the table a home made tube amplifier and recently build Philips FM13 tube tuner. On the shelf a Mendocino Motor made from a kit and a home brew Phono Oscillator (Steampunk style) build with tubes. To see how it was made click link: https://youtu.be/7X2BdNh-p6I
